Guidewires

Custom Guidewires for over 25 years

  • Length: 20cm to 180cm
  • Diameter: 0.018" (.46mm) to 0.080" (2.04mm)
  • Core Design (Fixed or Movable)
  • High Quality Stainless Steel (302, 304, or 316)
  • Stainless Steel with Nickel Titanium Core
  • PTFE Coated (pre or post coat)
  • Visimark™ available
Tip Flexibility is determined by the length of the grind on the end of the core wire (Supple to Stiff)

PTFE Guidewires

Post-coated thickness specification: .0001” – .0004” per side
Pre-coated thickness specification: .0001” – .0003” per side
Coated Stainless Steel Guidewires with Optional Nitinol Core

Standard Tolerances

O.D Tolerances:

  • For wires up to and including .021”: +.000/-.001”
  • For wires above .021”: +.000/-.002”

Length Tolerances:

    • Up to and including 120cm: ± 1cm
    • Over 120cm lengths: ± 2cm
Standard ribbon size: .003” thick x .010” wide
Safety Ribbon is required on any length equal to or greater than 100cm
Flex tolerances: ± 0.5cm / 3mm “J” tolerance: ± 1mm

Designed to your specifications

Get Started

If you would like more information or to request an appointment please call or contact us.
612-501-0415
